Plug Valve

Lubricated Plug Valve
Size NPS 1/2″-4″
Pressure Class 150-300
Material WCB, LCB, CF8, CF3, CF3M, CF8M
Design & Manufacture Std. API 6D,API 599,ASME B16.34
Face to Face Std. API 6D,ASME B16.10
End Connection Std. ASME B1.20.1,ASME B16.5,ASMEB16.25
Test standard ISO5208,API 6D
Structure Type Short Pattern, Regular Pattern, Venturi Pattern, Full Bore Pattern
Operated Way Lever, Gear, Pneumatic, Electric
Pressure     Plug Valve
Size NPS 2″-24″
Pressure Class 150-1500
Material WCB, LCB, CF8, CF8M, CF3, CF3M
Design & Manufacture Std. API 6D,API 599,ASME B16.34
Face to Face Std. ASME B16.10,API 6D
End Connection Std. ASME B16.5,ASME B 1.20.1 ,ASME B16.25
Test standard 5208,API 6D
Structure Type Short Pattern, Regular Pattern, Venturi Pattern, Full Bore Pattern
Operated Way Lever, Gear, Pneumatic, Electric
